Tinplate Sheet Supplier | Precision Coated Steel for Packaging
Huaxiao-Alloy supplies premium tinplate sheet (tinned plate) for food cans, aerosols & industrial packaging. ASTM/JIS-certified, 0.13–0.49mm thickness, custom sizes. Compare tin plated steel vs. TFS/ECCS. Request a quote for food-grade tin plated sheet metal!
What is Tinplate? Core Definition & Huaxiao-Alloy’s Process
Tinplate
Base Steel: Ultra-clean, low-carbon (0.01-0.13% C) steel for maximum ductility. Electroplating: Precision tin coating (0.1–2.0 g/m² per side) with chromate or oxide passivation. Oiling: Food-safe dioctyl sebacate (DOS) or acetyl tributyl citrate (ATBC) oils for corrosion resistance.
Food Safety: Meets FDA/EC1935 standards – ideal for canned foods/beverages. Solderability: Enables seamless can seam welding. Barrier Protection: Tin resists oxidation, sulfur staining, and acidic contents.
Huaxiao-Alloy Tinplate Sheet Specifications
We supply globally certified tinplate (ASTM A623, JIS G3303, EN 10202) in custom sizes.
| Parameter | Range | Tolerance |
|---|---|---|
| 0.13 mm – 0.49 mm | ±0.01 mm | |
| 600 mm – 1,250 mm | ±0.5 mm | |
| 1.1 g/m² – 11.2 g/m² (per side) | ±0.2 g/m² | |
| T1 (Soft) to T5 (Hard) | HR30T: 52–68 |
(Custom widths/lengths available – request cutting service)
| Coating Weight (g/m²) | Type | Best For |
|---|---|---|
| Light Coat | Dry food, non-aggressive products | |
| Medium Coat | Fruits, vegetables, carbonated drinks | |
| Heavy Coat | Acidic foods (tomato, citrus) |
Tinplate vs. Alternative Coated Steels: The Huaxiao Advantage
While
| Property | Huaxiao Tinplate | TFS (Cr/CrOx) | ECCS | Galvanized Steel |
|---|---|---|---|---|
| Excellent (Sn barrier) | Good (Cr barrier) | Very Good (Cr + epoxy) | Poor (Zn reacts with acids) | |
| Poor (requires welding) | Poor | Poor | ||
| Excellent (inks adhere) | Good | Fair | ||
| FDA-Compliant | FDA-Compliant | Not for direct contact | ||
| $$ | $ | $$$ | $ | |
| Canned tuna, soup | Can ends, crowns | Beverage cans | Construction, ducts |
Tinplate is irreplaceable for soldered food cans requiring long shelf life. TFS is cheaper but limited to can ends/lids due to poor solderability. ECCS excels in beverage cans needing high print quality. Galvanized steel is unfit for food contact due to zinc migration.
Why Choose Huaxiao-Alloy Tinplate?
We solve critical packaging challenges with:
Precision Metallurgy - Base steel hardness tailored to temper grades (T1-T5) for deep drawing (DRD cans) or rigidity (food trays).
- Consistent coating weights (±0.1 g/m²) via AI-controlled electroplating.
Sustainable Solutions - Recyclable indefinitely (steel’s magnetic properties aid recovery).
- Thin coatings (≤1.5 µm) reduce tin usage by 40% vs. industry averages.
Formability Expertise DR-8 (DR550) grade for complex shapes (e.g., aerosol cones). DR-9 (DR620) for high-strength food cans.
Global Compliance - Certifications: ISO 9001, ISO 22000, BRCGS Packaging.
- Traceability: Mill test reports with heat/coil numbers.
Huaxiao-Alloy supplies premium tinplate sheet (tinned plate) for food cans, aerosols & industrial packaging. ASTM/JIS-certified, 0.13–0.49mm thickness, custom sizes. Compare tin plated steel vs. TFS/ECCS. Request a quote for food-grade tin plated sheet metal!
Pre-Painted Galvalume Steel Coil / Sheet / Plate
Huaxiao-Alloy’s Pre-Painted Galvalume® Steel combines
Pre-Painted Galvanized Steel Coil / Sheet / Plate
Huaxiao-Alloy’s Pre-Painted Galvanized Steel combines
Galvalume Steel Coil / Sheet / Plate
Huaxiao-Alloy’s Galvalume® (55% Al-43.4% Zn-1.6% Si) delivers
Zinc-Aluminum-Magnesium Coated Steel Coil / Sheet / Plate
Huaxiao-Alloy’s
Hot-Dip Aluminum Coated Steel Coil / Sheet / Plate
Huaxiao-Alloy’s Hot-Dip Aluminum Coating transforms carbon steel into an
FAQs: Tinplate Sheet Essentials
None. “Tinplate,” “
Yes. Specify
Strength: Tinplate withstands higher pressure (ideal for carbonated drinks). Recyclability: Both are recyclable, but steel cans are magnetic for easier sorting. Cost: Tinplate is cheaper for high-volume production.
Tinplate withstands retort sterilization (121°C/250°F) but avoid prolonged >150°C/302°F exposure to prevent tin melting.
Both. We offer coils (ID: 508 mm/20″) or cut-to-size sheets (custom dimensions available).
- Recycled content: Up to 35% post-consumer steel.
- Thin coatings reduce tin mining impact.
- Water-based passivation avoids hexavalent chromium.
