WHY ELECTRICAL STEEL PRICING ISN’T SIMPLE
Electrical steel costs range from 15.00/kg – a 10x variance driven by:
- Core Loss Performance (P1.5/50 or P1.7/50 in W/kg)
- Thickness Tolerance (±0.02mm ultra-thin vs. ±0.05mm standard)
- Certifications (IEC, ASTM, JIS, OEM-specific)
- Coil Widths/Coatings
At Huaxiao-Alloy, we supply certified electrical steel with transparent pricing for motors, transformers, and EV components.
SECTION 1: ELECTRICAL STEEL COST DRIVERS EXPLAINED
1. Material Type & Grade
| Category | Key Grades | Price Range ($/kg) |
|---|---|---|
| Standard NGOES | M400-50A, M350-50A | 2.80 |
| High-Perf. NGOES | 35H300, JNEH8000 | 6.00 |
| CGO (CRGO) | M085-27P5, 30P105 | 7.50 |
| Hi-B GOES | 27ZDKH90, 23ZDKH85 | 12.00 |
| Thin-Gauge HGO | 0.18mm JGHF® | 15.00 |
Spot prices as of Q2 2024, FOB China – 5 MT MOQ
2. Processing & Tolerances
- Laser Domain Refinement: +3.00/kg (15–25% core loss reduction)
- Thickness Precision:
- ±0.05mm: Baseline
- ±0.02mm: +8–12% cost
- Stress Relief Annealing (SRA): +$0.80/kg
3. Volume & Logistics
- < 5 MT: +15–25% (small-order premium)
- > 20 MT: Volume discounts (8–12%)
- EU/US Stock: +0.80/kg for bonded warehouse access
SECTION 2: HUAXIAO-ALLOY’S PRODUCT PORTFOLIO & PRICING
NGOES for Motors & Generators
| Product | Specifications | Price ($/kg) |
|---|---|---|
| 35H300 NGOES Coil | 0.35mm, P1.5/50 ≤4.0 W/kg, C5 coating | 4.40 |
| JNEH8000 EV Grade | 0.30mm, P1.0/400 ≤25 W/kg, Z-coating | 8.60 |
| Applications: EV traction motors (IPM), industrial servo motors |
GOES for Transformers
| Product | Specifications | Price ($/kg) |
|---|---|---|
| 27ZDKH90 Hi-B Coil | 0.27mm, P1.7/50 ≤0.85 W/kg, ZML coating | 10.50 |
| 0.18mm HGO Sheet | P1.0/400 ≤40 W/kg (100 kHz), laser-scribed | 15.00 |
| Applications: High-efficiency power transformers (>99% efficiency), 800V EV chargers |
SECTION 3: REAL-WORLD COST ANALYSIS
Transformer Core (500 kVA, 30P105 CGO)
- Material Cost: 2,400 kg × 13,920**
- With Hi-B (27ZDKH90): 2,400 kg × 22,800**
- Savings: Hi-B reduces no-load loss by 25% → $4,200/year energy saved → ROI in 2.1 years
EV Motor Stator (JNEH8000 NGOES)
- Material Cost: 85 kg × 671.50**
- Impact: Enables 5.3% WLTP range increase vs. M350-50A ($4.20/kg)
SECTION 4: WHY CHOOSE HUAXIAO-ALLOY?
Direct-Mill Pricing: Bypass traders (5–15% cost savings)
Certified Quality: Full MTRs per IEC 60404-8 (Epstein test reports)
Global Logistics: FOB China or bonded EU/US stock (Hamburg, Houston)
Technical Support: Grade optimization to reduce TCO
Case Study: Switched a German EV maker from M330-35A to JNEH8000 – saved $28,000/year via reduced core losses despite 88% higher material cost.
CONCLUSION: INVEST IN PERFORMANCE, NOT JUST PRICE
While standard NGOES starts under $2.00/kg, premium electrical steels deliver ROI through:
- 25–40% energy loss reduction
- Extended equipment lifespan
- Compliance with DOE, EU Tier DZ, China GB 20052
A: Core loss performance drives cost:
- Premium Grades (e.g., Hi-B 27ZDKH90): Laser-scribed domains reduce hysteresis losses by 20–30%, but add 3.00/kg in processing. Thinner gauges (0.18mm) require advanced rolling tech.
- Value Engineering Tip: For 50/60 Hz transformers, 0.27mm Hi-B often delivers better ROI than 0.23mm despite lower base cost.
A: Compliance adds 5–15% but reduces risk:**
- Essential: IEC 60404-8 (Epstein testing), ASTM A876
- Industry-Specific: EN 10107 (EU), JIS C 2553 (Japan), GB/T 2521 (China)
- OEM Approvals: Siemens, Hitachi ABB, BorgWarner specs (test reports add 0.80/kg)
Huaxiao-Alloy provides full MTRs with chemical, magnetic & mechanical data.
A: Non-standard sizes increase price:**
- Width: 1000–1250mm is standard; <600mm or >1500mm adds 7–12% (slitting/scrap loss).
- ID/OD: 510mm ID coils cost 3–5% less than 400mm ID (shipping efficiency).
- Order Volume: MOQ is 3 MT; discounts start at 20 MT (8–12% savings).
A: Key drivers include:**
- Silicon (~$3,500/MT): 60–70% of material cost.
- Cobalt/Nickel: Used in some NGOES grades (track LME futures).
- Logistics: China → EU/US shipping adds 1.20/kg.
Huaxiao offers quarterly price locks for orders >50 MT.
A: Yes – strategic compromises exist:**
- Transformers: Use CGO (30P105) instead of Hi-B for distribution units <50 MVA.
- EV Motors: Opt for 0.30mm JNEH8000 over 0.27mm JNEH7000 unless peak RPM >18,000.
- Prototyping: Request “secondary” coils (cosmetic flaws only) for 15–20% discount.
A: We bridge gaps others can’t:**
| Factor | Mills | Traders | Huaxiao-Alloy |
|---|---|---|---|
| Pricing | Low but 50+ MT MOQ | +25–40% markup | Mill-direct (+7% fee) |
| Testing | Batch-level only | Rare | Per-coil Epstein tests |
| Inventory Flexibility | 12–16 week lead time | Limited grades | Bonded EU/US stock (72h) |
: Huaxiao’s quotes detail:**
- Base price/kg (FOB Shanghai or CIF destination)
- Testing costs (e.g., Epstein, salt spray)
- Processing (slitting, SRA annealing)
- Incoterms (EXW, FOB, CIF)
- Validity period (30–60 days)
Request sample quote breakdown.
A: Yes – we guarantee:**
- Epstein test results (IEC 60404) within ±3% of quoted P1.7/50 or P1.5/50 values.
- Material traceability (heat number, mill origin).
- Performance validation for OEM designs.
